LinearFlow InGround Flex Dynamic White

LINEARFLOW INGROUND FLEX DYNAMIC WHITE is an innovative rigid in-ground lighting solution with tunable white LEDs from 2200K to 5700K designed for high-traffic environments and areas exposed to water. The flex version can be bend bent horizontally, vertically or sometimes both.

By seamlessly integrating a LED strip, continuous reinforced silicone diffuser cover and metal raceway profiles into a single system, it delivers exceptional durability, waterproof performance,
and impact resistance.

Available in three channel options suitable for walk over to 30T driver over installations, LINEARFLOW INGROUND can be specified with confidence for everything from pedestrian walkways and plazas to roads, driveways, and other heavy-duty applications.

Description

Features

Product Type: Flex Walk and Drive Over Linear Light with Dynamic White LEDs
IP Rating: IP68, suitable to be fully submersible
Bending Orientations: Vertical or Horizontal
General Product Code: 71311x3x
Light Source:Epistar SMD 3015 LEDs
Colour Options (CCT): 1800K – 5000K
Colour Rendering: 80+ CRI
LED Lifetime (LM-80): 50,000 Hours (70% Lumen Maintenance)
Luminous Output / Efficacy: Up to 250 lm/m : Up to 23lm/W

Warranty: 5 years
Resistant to: Solvents, UV, Heat and Saltwater
Jacket Material: Silicone
LED Power Available: 12W, 10.5W
Mounting Profile lengths: 500mm, 1000mm (Custom lengths available on special request)
Supply Voltage: 24Vdc Constant Voltage
Power Supply: Remote Constant Voltage Power Supply with Dimmer options
Mounting: Rigid Aluminium and Stainless Steel Channels

LinearFlow InGround Flex

Downloads

Full Specification Sheet

Driver Sheet

LinearFlow Inground Flex Dynamic White product codes

71311*3* – [LED Colour Code] – W – [Length Code] – [Wire Code]

71311235-81850-W-0500-C0B0

LINEARFLOW INGROUND DYNAMIC WHITE IP68, White Silicone Outer Casing, Horizontal Bend, 12W/m LEDs, CRI 80+ 1800K – 5000K at 500mm Cut Length, Single Ended Wiring with Injection Moulded End Caps.

END1 = IP68 Injection Moulded End Feed Cap with 0.3m Cable
END2 = IP68 Injection Moulded Dead End Cap with NO Cable

Total Length (+ End Caps) = 500mm, Light Emitting Surface Length = 500mm (6 x 83.3mm LED Modules),
Strip wattage = 6W (6 x 1 Module Power), Strip output = Up to 125lm.

Principle variants, see Specification Sheets for full details.

ARTICLE NUMBER	DESCRIPTION
71301134	LinearFlow Inground Dynamic White LED, Silicone casing, vertical bend, 10.5W/m
71301234	LinearFlow Inground Dynamic White LED, Silicone casing, horizontal bend, 10.5W/m
71301135	LinearFlow Inground Dynamic White LED, Silicone casing, vertical bend, 12W/m
71301235	LinearFlow Inground Dynamic White LED, Silicone casing, horizontal bend, 12W/m

Product parameter codes

Length Code	[0084] to [10000] .
LED Colour Code	80+ CRI: 1800K -5000K [81850]
Wire Code	see spec. sheet for details

Accessories codes

(See Product Specification Sheet for additional details)

Stainless steel housing channel	71319210-XXXX Lengths Available 500/1000 Custom lengths available on special request
Stainless steel housing silicone diffuser /m (Max 10m)	71319500-XXXX
Stainless steel housing protective pvc cover /m (Max 30m)(for installation only)	71319510-XXXX
Stainless Steel Plain End Cap	71319220
Stainless Steel Cable End Cap	71319221
Silicone Cover Locking bracket	71319222
Rubber Grommet	71319260
Stainless Steel Fixing Bracket	71319241
Support Stand Kit	71309240
Aluminium Straight Joining Bracket	71309320
Field Installable female connector + 500mm Cable	71309170-0500
Side Cable Feed Profile	71319223

Driver codes

(Example list, see Driver Sheet for full detail including fitting loading)

273-858-040	LED Constant Voltage Power Supply 24Vdc 40W 100-305Vac 47-63 Hz. WIth 300mm input & output leads
273-858-080	LED Constant Voltage Power Supply 24Vdc 80W 100-305Vac 47-63 Hz. WIth 300mm input & output leads
273-858-100	LED Constant Voltage Power Supply 24Vdc 100W 100-305Vac 47-63 Hz. WIth 300mm input & output leads
273-858-150	LED Constant Voltage Power Supply 24Vdc 150W 100-305Vac 47-63 Hz. WIth 300mm input & output leads
273-858-240	LED Constant Voltage Power Supply 24Vdc 240W 100-305Vac 47-63 Hz. WIth 300mm input & output leads
273-848	LED Single Channel Dimmer 6A 6-24Vdc, DMX / 0-10V / 1-10V, with DMX in & out, 10V In & out.
205-057	Rotary Potentiometer for 1-10V Controllers
205-029	OTDALI DIM LED PWM DALI Dimmer interface 5A 12/24Vdc 50/120W
273-606-1	LED Constant Voltage DALI Dimmer Single Channel 12/24V 8A twin output
273-606-2	LED Constant Voltage DMX Dimmer Single Channel 12/24V 8A twin output
273-606-3	LED Constant Voltage Analogue (0-10V) Dimmer Single Channel 12/24V 8A twin output
273-607-1	LED Constant Voltage DALI Dimmer Two Channel 12/24V 8A two output
273-607-2	LED Constant Voltage DMX Dimmer Two Channel 12/24V 8A two output
273-550	LED Constant Voltage DALI & DMX Dimmer Four Channel 12/24V 24A four output (6A per output)
205-074	LED Constant Voltage DMX Dimmer Four Channel 12/24V 16A four output (4A per output)
273-604-1	LED Constant Voltage Integrated 100W PSU & DALI/DMX Dimmer Four Channel 12/24V 8A
