Wibre 4.0490

The 4.0490 is Wibre’s largest Surface mounted adjustable spotlight. Designed to perfectly illuminate medium to large fountains and waterside architecture.

Particularly suitable for adding drama to fountains and high water jets up to 50m tall.

IP68 rated for use in water up to 25m water depth. Also IP69 rated for protection against high pressure and high jet water temperatures. Housing made with 316Ti 1.4571 stainless steel.

High-performance LEDs in single colour 3000K, 4500K or 6500K with up to 18600lm output. Also RGB+white & other colour options.

25° optical array is the standard beam angle but other distributions are available to special order.



Description

Features

  • Manufacturer: Wibre
  • Product Type: Underwater IP68 Surface Spotlight lights
  • General Product Code: W.4.0490
  • Light Source: White POW-LEDs, RGBW Multichip POW-LED
  • Standard Colour Range (CCT / Colour): 3000K, 4500K, 6000K, RGB+3000K, RGB+4500K, RGB+6000K
  • Luminous Output: Up to 18600 lm
  • Output Beam: Medium 25°. (Custom options for 10°, 50°, 120°, 50°x15° elliptical)
  • IP Rating: IP68 for underwater use up to 25m
  • IP Rating: IP69 for protection against high pressure and high jet water temperatures
  • Supply Voltage: Constant current – White: 12Vdc Max. RGB-W: 24Vdc max.
  • Power supply: Remote Constant current Drivers with Dimming options
  • Mounting: Surface Mount adjustable through 90°
  • Materials: Stainless Steel 316Ti 1.4571

Wibre 4.0290

Downloads

Brochure

Install sheets

Wibre 4.0490 product codes

ARTICLE NUMBERDESCRIPTION
4.0490.00.11Wibre Centum Surface Mount IP68+IP69 Foutain Light 32 POW-LED 6000K Asymmetric Mixflux 120W 12VDC
4.0490.00.12Wibre Centum Surface Mount IP68+IP69 Foutain Light 32 POW-LED 3000K Asymmetric Mixflux 120W 12VDC
4.0490.00.13Wibre Centum Surface Mount IP68+IP69 Foutain Light 32 POW-LED 4500K Asymmetric Mixflux 120W 12VDC
4.0490.00.41Wibre Centum Surface Mount IP68+IP69 Foutain Light 32 Multichip RGB+6000K Asymmetric Mixflux 150W 24VDC
4.0490.00.42Wibre Centum Surface Mount IP68+IP69 Foutain Light 32 Multichip RGB+3000K Asymmetric Mixflux 150W 24VDC
4.0490.00.43Wibre Centum Surface Mount IP68+IP69 Foutain Light 32 Multichip RGB+4500K 150W 24VDC
